Features of MIG-220P pulse welding machine
1. New Appearance Design, Compact Digital Control Panel, SYN Adjustment;
2. Integrated Wire Feeder With Single Drive Wire Feeder, Ensure Wire Feeding Stable;
3. Single Pulse And Double Pulse Can Be Chosen, Suitable For Welding Super-thin 0.45mm Aluminum Plate, Carbon Steel, Stainless Steel;
4. With Wheels, Easy To Move, High Convenience For MIG Welding;
5. International Brand IGBT-35KHZ And Rectify Tube;
6. Quick Welding Speed, Little Splash, Deep Pool, Good Welding Appearance;
7. High Duty Cycle, Efficiency Is 3 Times Of Traditional Argon Welding, Energy Saving,High Reliability.
Model | MIG-220P | MIG-220P M |
Input Power Voltage(VAC) | 1PH AC 220V/ 3 PH AC 380V | 1PH AC 220V |
Rated Input Capacity(KVA) | 6.4 | 6.4 |
Rated Input Current(A) | 29/9.8 | 29/9.8 |
No-load Voltage(V) | 65 | 65 |
Output Current Range(A) | 50-220 | 50-220 |
Rated Duty Cycle(%) | 60 | 60 |
Diameter Of Rod(mm) | 0.8-1.2 | 0.8-1.2 |
Insulation Class | F | F |
Protection Class | IP21 | IP21 |
Efficiency(%) | 85 | 85 |
Power Factor( cosφ) | 0.93 | 0.93 |
Weight(kg) | 25 | 25 |
Packing Dimensions(cm) | 60*38*64 | 60*38*64 |
